TPMC150-A2

Resolver Signal Conditioning Adapter with Reference Oscillator for TPMC150

  • Adapts signal levels of Synchro/Resolver I/O
  • Onboard Reference Oscillator
  • Individually built to customers synchro or resolver specification
  • Factory installed on the TPMC150
  • Required for each channel of the TPMC150

Last-Time-Buy date:

30/11/2024

Product status: Discontinued

RoHS complaint Operating Temperature Range -40 °C to +85 °C

Signal Conditioning Adapters are required for each channel of the TPMC150 to adapt the signal levels of the Synchro/Resolver I/O.

Signal Conditioning Adapters will be built individually to customers synchro or resolver specification. Signal Conditioning Adapters are always factory installed on the TPMC150. Therefore the signal and reference voltages and the reference frequency must be specified at time of order.

PRODUCT VARIATIONS

TPMC150-A2-01R

Signal Conditioning Adapter with Reference Oscillator (2 Vrms / SE, 4 Vrms / 4 KHz, Resolver)

Signal voltage: 2 Vrms (single-ended); Reference input: 4 Vrms / 4 KHz; Resolver
TPMC150-A2-03R

Signal Conditioning Adapter with Reference Oscillator (2 Vrms / DIFF, 7 Vrms / 3 KHz, Resolver)

Signal voltage: 2 Vrms (differential); Reference output: 7 Vrms / 3 KHz; Resolver
TPMC150-A2-xxR

Signal Conditioning Adapter with Reference Oscillator (customized)

Request a customized Signal Conditioning Adapter. Therefore specify signal and reference voltage and the reference frequency.
